Industries across the board require a wide variety of valves to meet the demands of their complex processes. Valves come in an extensive range of materials tailored to suit different applications. Common options include PVC, carbon steel, stainless steel, cast iron, and ductile iron. This article will focus on two of these materials: ductile iron and cast iron.

The debate surrounding "ductile vs. cast iron valves" has persisted for years, as many are unfamiliar with the key distinctions between these materials.

Fortunately, understanding the differences between ductile iron and cast iron valves is straightforward, as they vary in just a few significant ways. In this post, we’ll break down the properties of both materials, highlighting their advantages and disadvantages. By the end, you’ll have a clear understanding of which material suits your needs best!

Specifications of Cast Iron Valves

Cast iron, often referred to as gray iron, is a time-tested metal that has been used for centuries. This alloy typically consists of 96%-98% iron, 2%-4% carbon, and small amounts of silicon. Its exceptional temperature resistance makes it suitable for high-heat applications, with some grades able to withstand temperatures exceeding 2100°F (1150°C).

The pressure capacity of cast iron valves depends on their pressure class. The two most common classes are **Class 125** and **Class 250**. At moderate temperatures, Class 125 cast iron flanges are rated for pressures between 150 and 200 psi, while Class 250 offers higher durability, handling pressures from 300 to 500 psi. It's important to note that pressure ratings can vary depending on the valve's end connection type.

One notable strength of cast iron is its durability under vibration. Even in environments with intense vibrations, cast iron remains robust and resistant to damage. However, its primary limitation lies in its lack of ductility. Cast iron is brittle, meaning any significant bending force can cause it to crack, rendering the valve unusable.

Despite this drawback, cast iron remains a popular choice due to its affordability. Compared to other metals, cast iron is one of the most economical options available, making it an excellent choice for cost-conscious buyers seeking reliable performance in suitable applications.

Specifications of Ductile Iron Valves

The second material under consideration is ductile iron, a modern iron alloy distinguished by its unique graphite structure in the form of nodules. This structural characteristic grants ductile iron remarkable flexibility, making it resistant to cracking or breaking when subjected to bending. While its temperature tolerance is slightly lower than that of cast iron, it remains impressive, with a maximum limit of 1350°F (730°C).

Ductile iron valves are classified by pressure classes, most commonly Class 150 and Class 300. At typical ambient temperatures, Class 150 ductile iron valves can maintain a seal at pressures up to 250 psi, whereas Class 300 valves can handle pressures as high as 640 psi.

This material offers excellent corrosion resistance, tensile strength, and yield strength, making it a reliable choice for demanding applications. Unlike cast iron, ductile iron's flexibility allows it to endure bending forces without breaking, making it ideal for high-stress environments.

However, one trade-off is cost. Ductile iron tends to be more expensive than cast iron due to its more complex composition and manufacturing process. Despite the higher price, it often proves to be a worthwhile investment for applications requiring enhanced durability and performance.

As a Chinese ductile iron valve manufacturer, solid provides you with a wide range of ductile iron valve types, please check:
