Brass vs. Stainless Steel Ball Valves: Which Is Better?
Ball valves are widely used for shut-off and flow control in piping systems, thanks to their durability and reliable sealing—even after long periods of inactivity. Compared to other valve types, they offer superior resistance to contaminated or corrosive materials.
These valves are commonly found across a range of industries, including:
- Oil and gas
- Food and beverage
- Automotive
- Power generation
- Pharmaceuticals
- General manufacturing
Typical applications for ball valves include:
- Chemical dosing and treatment systems
- Irrigation and water purification equipment
- Car wash systems
- Outdoor hose setups
- Washing machines and dishwashers
Ball valves are manufactured from various materials, with brass and stainless steel being two of the most commonly used. Read on to explore the differences between stainless steel and brass ball valves to help you choose the right option for your next project.
What Are Stainless Steel Ball Valves?
Stainless steel ball valves are durable and reliable components used in shut-off and control applications. Made from an iron alloy combined with chromium and nickel, stainless steel offers excellent resistance to leaks, high temperatures, and pressure—making it a suitable choice for demanding environments.
Among the various grades, 316 stainless steel stands out for its superior corrosion resistance. This grade contains a higher nickel content and includes molybdenum, a silvery metal known for its high melting point and enhanced resistance to chlorides. As a result, 316 stainless steel ball valves are ideal for use in highly corrosive settings, including marine and chemical processing applications, where exposure to salt or harsh chemicals is common.
What Are Brass Ball Valves?
Brass valves are made from a metal alloy primarily composed of copper and zinc, with small amounts of other metals. Some brass valves may contain trace amounts of lead—typically less than 2%. However, due to health concerns, the U.S. Food and Drug Administration (FDA) only permits the use of certified lead-free brass in applications involving potable water or food processing.
In most cases, the first component to degrade in a metal ball valve is the soft seal. As a result, the overall service life of a brass ball valve is often comparable to that of a stainless steel valve, provided the application does not involve corrosive substances.
Brass also has better weldability than stainless steel, which can make it a more flexible and cost-effective choice for certain industries and custom installations where corrosion resistance is not a primary concern.
Applications for Stainless Steel Ball Valves
Due to their corrosion resistance, ability to withstand high temperatures, and performance in high-pressure environments, stainless steel ball valves are widely used in industrial, manufacturing, and construction applications. Common uses include:
- Petroleum refining
- Marine operations
- Brewing systems
Applications for Brass Ball Valves
In most applications, brass ball valves offer comparable performance and longevity to stainless steel valves. However, for environments with extreme pressure or temperature requirements, stainless steel or other more durable materials may be better suited. In these cases, specialized seal materials—typically made of P.T.F.E.—would also be necessary, as the seals are usually the weakest link in any valve.
Brass ball valves are commonly used in residential and commercial plumbing, water wells, HVAC systems, and other general applications. For applications involving drinking water or food processing, only certified lead-free brass ball valves can be used to comply with FDA regulations.
The bottom line: Brass ball valves are a cost-effective option for most applications, as long as they do not handle highly corrosive materials.
Stainless Steel Ball Valves vs. Brass Ball Valves
Stainless Steel Ball Valves | Brass Ball Valves | |
Material Composition | Iron alloy made from nickel and chromium (and sometimes molybdenum) | Copper alloy that includes zinc and occasionally additional metals |
Cost | More costly than leaded and lead-free brass ball valves | Less costly than stainless steel ball valves, more costly than plastic ball valves |
FDA Approval | Approved by the FDA for use in the food and beverage industry | Not approved by the FDA unless certified lead-free |
Softness | Harder than brass, making it more challenging to seal (for example, by welding) | Softer than stainless steel, making it more easy to seal (for example, via welding) and more efficient to machine |
Corrosion Resistance | Highly corrosion resistant; the preferred material for use in corrosive environments, including marine applications | Can withstand corrosive environments better than plastic but not as well as stainless steel; however, can be compatible with some materials not compatible with stainless steel |
Pressure Ratings | Higher pressure ratings than brass; more resistant to high pressure | Lower pressure ratings than stainless steel; less resistant to high pressure |
Temperature Resistance | Can handle and last longer at higher temperatures than brass ball valves | Not as suitable for high temperature situations as stainless steel ball valves |
When compared to brass ball valves, stainless steel ball valves perform better in corrosive environments, can withstand higher temperatures and pressures, and are safe for use in food and beverage applications without posing health risks.
On the other hand, brass ball valves are more affordable and offer greater versatility in processes that require welding. Both types of ball valves provide effective solutions when used in the right conditions.
