DIN Ball Valve

DIN ball valve is designed to provide a reliable and efficient solution for controlling fluid flow in various industrial applications. The valve is constructed from high-quality materials and manufactured with precision, ensuring it delivers outstanding performance and longevity.

The DIN ball valve features a full bore design, which allows for maximum flow and minimal pressure drop. The valve body is made of carbon steel, stainless steel or brass, depending on the specific application requirements. The ball, stem, and seats are also made from high-quality materials, providing durability and resistance against wear and corrosion.

The ball valve's compact and robust design makes it easy to install and maintain, and its simple operation makes it perfect for both manual and automated systems. The valve's quarter-turn operation provides quick and reliable control over fluid flow, making it ideal for use in applications that require frequent changes in flow rate.

The DIN ball valve is available in various sizes ranging from DN15 to DN600, making it suitable for a wide range of fluid handling applications. The valve conforms to the DIN standards, ensuring it meets the required safety and quality standards. Additionally, it can operate effectively in temperatures ranging from -20℃ to 180℃.

In summary, the DIN ball valve is a high-performance, durable, and reliable valve solution for various industrial applications. Its full bore design, high-quality materials, and ease of installation and operation make it a popular choice among engineers and system designers worldwide. Whether for manual or automated control, the DIN ball valve is an ideal valve for controlling fluid flow in various industrial processes.

Size: DN15-DN300

Material: WCB, CF8, CF8M, CF3, CF3M

Two/Three-Piece body, floating ball

Face to face dimension: DIN 3202 F4/F5

Flanged end: DIN 2533

Pressure: PN16, PN25, PN40, PN64

Type of operation: lever, worm gear actuator, electric actuator, pneumatic actuator to ISO 5211 standard.
